VL161 USB Type-C Data Switch For USB 3.1

Description



VL161 is 2:4 differential channels mux/demux switch for USB 3.1 application, for switch signal performance supports up to USB 3.1, and using QFN-28 3.5x4.5mm Green package.

Block Diagram

Key Features

  • 4:2 10Gbps USB Type-C Data Switch
  • 2 Differential Channel, 2:1 MUX/DeMUX
  • Low power consumption with 0.5mA active
  • High DC common mode voltage supporting to 2.2V
  • 28 pins QFN 3.5 x 4.5mm package
  • ESD > 4KV, CDM > 500V
  • Lead(Pb)-Free and RoHS compliant
  • MUX
    - Insertion loss: 1.5dB @ 5GHz typ.
    - Return loss: 15dB @ 5GHz typ.
    - Crosstalk Isolation: 30dB @ 5GHz typ.
    - Off Isolation: 15dB @ 5GHz typ.
